This is a compact adjustable power supply that delivers a stable voltage and currents up to 3 amperes. The circuit is very conventional and its voltage output can be varied from 1.25 volts to 25 volts.
The main module is the LM350 IC which integrates a voltage regulator and a power stage. It also has a built-in overload protection which activates at 30 watts of power dissipation. The voltage output is set by connecting the “adj” pin of the IC to the voltage divider made of R1 and P1. The output voltage can be calculated using the following formula:

This power supply circuit is highly stabilized that its output voltage will drop only 0.005% even though the load changes from 0 to 100%. Another excellent capability is that the output voltage will change only by 0.01% if the input voltage fluctuates. The capability if the circuit to be adjusted from 0.1V up to 50V is due to the application of opamp IC CA3130 in the circuit. Transistor T4 raises the output voltage to higher level, and at the same time it separates the lower level opamp from the high level of the output voltage. The reference voltage is supplied by IC1. It is a temperature compensated transistor array with 5 transistors. Four of these transistors are used as reference diodes and the fifth one sets the output impedance of the reference source.
